INSPECTION - TURBOCHARGER

Visually inspect the turbocharger and exhaust manifold gasket surfaces. Replace stripped or eroded mounting studs.

• Cracks in the turbine and compressor housing that go completely through.
• Cracks in the mounting flange that are longer than 15 mm (0.6 in.).
• Cracks in the mounting flange that intersect bolt through-holes.
• Two cracks in the mounting flange that are closer than 6.4 mm (0.25 in.) together.
