INSTALLATION

CAUTION: Use care when installing the caliper onto the disc brake adapter to avoid damaging the guide pin boots.

NOTE: When installing the caliper guide pin bolts (2, 3), make sure the bolts are put back in the same locations as when removed to avoid NVH issues. Depending on the build date and services performed, the location of the bolt with the special sleeve on the tip (3) can vary.
