INSTALLATION

NOTE: Perform STEP 1 through STEP 5 on each side of the vehicle to complete pad set installation, then proceed to STEP 6.

NOTE: Make sure that the audible wear indicators (if equipped) are placed toward the top when the inboard brake pads are installed on each side of the vehicle.

CAUTION: Use care when installing the caliper (4) onto the adapter bracket (1) to avoid damaging the boots.

NOTE: When installing the caliper guide pin bolts (2, 3) make sure that the one that has a special sleeve on the end is installed in the upper mounting hole.
