HOUSING-HVAC

NOTE: The HVAC housing must be removed from the vehicle and disassembled for service of the A/C evaporator.

NOTE: LHD model with A/C shown in illustrations. RHD and heater-only models similar.

NOTE: If the foam seal for the flange is deformed or damaged, it must be replaced.

NOTE: If the foam insulator around the A/C evaporator is deformed or damaged, the insulator must be replaced.

NOTE: If the seal around the evaporator tube tapping block is deformed or damaged, the seal must be replaced.
