GRAVITY BLEEDING CLUTCH HYDRAULIC CIRCUIT

NOTE: Do not allow clutch master cylinder to run dry while fluid exits bleed port. If master cylinder runs dry, it is necessary to remove clutch master cylinder, position vertically (with push rod down) for 10 seconds, and reinstall.

POWER BLEEDING CLUTCH HYDRAULIC CIRCUIT

NOTE: Use Bleeder Cap/Modified reservoir cap adapter Snap-on #901-059 or equivalent

NOTE: Use Service Filling Machine/Brake power bleeder Brake power bleeder or equivalent

NOTE: Use Bleeder Container To capture hydraulic fluid and Transparent Bleeder Hose To route fluid to container

NOTE: Pedal load should be approximately 25 lbs. For gas vehicles, reserve should not be below 30 mm. For diesel vehicles, reserve should not be below 40 mm.
